Keysight Technologies AC6801B - Instrument Ratings

Instrument Ratings
AC6801B AC6802B AC6803B AC6804B
Output Rating for AC mode (155 V/310 V range)
Rated voltage range 1 to 155 Vrms/2 to 310 Vrms
Maximum rms current 5 A/2.5 A 10 A/5 A 20 A/10 A 40 A/20 A
Maximum power 500 VA 1 kVA 2 kVA 4 kVA
Frequency range 40 Hz to 500 Hz
Output Rating for DC mode (155 V/310 V range)
Rated voltage range 1.4 to 219 Vrms/2.8 to 438 Vrms
Maximum DC current 4 A/2 A 8 A/4 A 16 A/8 A 32 A/16 A
Maximum power 400 VA 800 VA 1.6 kVA 3.2 kVA
Input Ratings
Voltage rating
100 to 120 Vrms/200 to 240 Vrms, 50 Hz or 60 Hz, single-phase
Voltage range
90 to 132 Vrms/180 to 264 Vrms (auto detected when the power is turned on)
Frequency range
47 Hz to 63 Hz
Apparent power
800 VA or less 1600 VA or less 3200 VA or less 6400 VA or less
Power factor
0.9 (typical)
Maximum input current
8 A/4A @ 100V/200V
6.7A/3.5A @ 120V/230V
16 A/8A @ 100V/200V
13.4 A/7.0 A @ 120/230V
32A/16A @ 100V/200V
26.8 A/14.0 A @ 120/230V
64 A/32A @ 100V/200V
53.6 A/28.0 A @ 120/230V
Environment
Operating environment
Indoor use, Overvoltage Category II
Temperature and humidity range
0 to 40 °C (32 to 104 °F), 20% to 80% R.H. non-condensing
Altitude
Up to 2000 meters
Acoustic noise
< 70 dbA
Physical
Dimensions (with safety covers) 428 × 128 × 350 mm
168.5 x 50.5 x 138”
428 × 128 × 350 mm
168.5 x 50.5 x 138”
428 × 128 × 550 mm
169 x 50.5 x 216.5”
428 × 256 × 600
mm\168.5"×101"×236")
Weight Approx. 8 kg
(17.64 lb)
Approx. 11 kg
(24.25 lb)
Approx. 16 kg
(35.27 lb)
Approx. 32 kg
(70.55 lb)
Input terminal IEC 320 inlet M4 terminal block M6 terminal block M6 terminal block
Output terminal M4 terminal block M4 terminal block M4 terminal block M6 terminal block
