Performance Test Record - AC6803B
Test Description Minimum Spec. Results Maximum Spec.
AC Voltage Programming and Readback Accuracy
155 Vrms @ 60Hz 154.4575 ______ V 155.5425
Front Panel Measurement Vrms - 1.125 V ______ V Vrms + 1.125 V
155 Vrms @ 500Hz 154.4575 ______ V 155.5425
Front Panel Measurement Vrms - 2.085 V ______ V Vrms + 2.085 V
310 Vrms @ 60Hz 308.915 ______ V 311.085
Front Panel Measurement Vrms - 2.25 V ______ V Vrms + 2.25 V
310 Vrms @ 500Hz 308.915 ______ V 311.085
Front Panel Measurement Vrms - 4.17 V ______ V Vrms + 4.17 V
Voltage Load Regulation
CV Load Effect Low Range @ 60 Hz Vout - 0.15 V ______ V Vout + 0.15 V
CV Load Effect Low Range @ 500 Hz Vout - 0.50 V ______ V Vout + 0.50 V
CV Load Effect High Range @ 60 Hz Vout - 0.30 V ______ V Vout + 0.30 V
CV Load Effect High Range @ 500 Hz Vout - 1.00 V ______ V Vout + 1.00 V
RMS Current Measurement Accuracy
Low Range Measurement @ 60 Hz Iout – 180 mA ______ A Iout + 180 mA
Low Range Measurement @ 500 Hz Iout – 300 mA ______ A Iout + 300 mA
High Range Measurement @ 60 Hz Iout – 90 mA ______ A Iout + 90 mA
High Range Measurement @ 500 Hz Iout – 150 mA ______ A Iout + 150 mA
Frequency Accuracy
Program 500 Hz 499.9 Hz ______ Hz 500.1 Hz
DC Voltage Programming and Readback Accuracy
+219 VDC Output 218.343 VDC ______ VDC 219.657
Front Panel Measurement Vout - 1.445 VDC ______ VDC Vout + 1.445 VDC
+438 VDC Output 436.905 VDC ______ VDC 439.095
Front Panel Measurement Vout - 2.89 VDC ______ VDC Vout + 2.89 VDC
DC Current Readback Accuracy
Low Range Measurement Iout – 160 mA ______ A Iout + 160 mA
High Range Measurement Iout – 80 mA ______ A Iout + 80 mA
