Front Panel Menu Reference
This is an overview of the front-panel menus.
Press [Menu] to access the front-panel menus.
For a menu navigation tutorial, see Use the Menu System.
Level 1 Level 2 Levels 3&4 Description
Output Voltage Sets output voltage and limits
AC Sets ACvoltage and limits
DC Sets DCvoltage and limits
Prog Programs voltage with optional analog board
Frequency Sets output frequency and limits
Range Selects voltage range
Coupling Selects output coupling
Current Sets output current limits
Phase Sets output-on phase
Measure IpkHold Displays or clears peak held current
Coupling Selects the measurement coupling
Average Selects number of measurements to average
Protect Current Configures current limiting
WDog Configures IO watchdog
Clear Clears protection conditions and displays output status
States Reset Resets instrument to the reset (*RST) state
SaveRecall Saves and recalls instrument settings
PowerOn Selects the power-on instrument state
2User Information
66 Keysight AC6800B Series Operating and Service Guide
