Welcome
This manual includes user, service, and programming information for the Keysight AC6800B Series of
compact AC sources, which can be readily used on the bench or in a test rack. The simple user
interface allows you to easily access and view setup and measurement information directly from the
front panel or programmatically.
Choose from models up to 4000 VA, all with 0 to 310 Vrms and 40 to 500 Hz output capability. Both
LAN/LXI Core and USB interfaces are standard. You can optionally choose to add GPIB or an analog
interface board to add basic transient signals.
Instrument Driver
In addition to using SCPI commands, you can also control the instrument using the IVI driver, available
at ivifoundation.org. The newest version can also be downloaded at
www.keysight.com/find/AC6800firmware.
Models and Options
The AC6800B Series includes four models and four options, as shown below.
Model Maximum Power (VA)
AC6801B 500
AC6802B 1,000
AC6803B 2,000
AC6804B 4,000
The AC6800B Series has four options, described below.
Option Description
AC68BRAC3 Rack mounting kit for AC6801B, AC6802B, and AC6803B
AC68BRAC6 Rack mounting kit for AC6804B
AC68GPBU GPIB interface board
AC68BALGU Analog interface board - controls the output with external analog signals in two modes:
EXT-AC: The AC output voltage varies according to the input DC signal.
EXT-DC: The input waveform is amplified and output.
Documentation, Firmware, and Technical Support
You can download the latest version of this document from www.keysight.com/find/AC6800B-doc .
The latest version is also available for mobile devices at www.keysight.com/find/AC6800B-
mobilehelp.
For the latest firmware revision go to the product page at www.keysight.com/find/AC6800B.
2User Information
64 Keysight AC6800B Series Operating and Service Guide
