STATus:OPERation:ENABle <value>
STATus:OPERation:ENABle?
Sets the value of the enable register for the Operation Status group. The enable register is a mask for
enabling specific bits from the Operation Event register to set the OPER (operation summary) bit of the
Status Byte register. The STATus:PRESet command clears all enable register bits.
Parameter Typical Return
Decimal sum of the bits in the register, default 0. For example, to enable bit 2 (value 4), bit 3 (value 8), and
bit 7 (value 128), use decimal sum 140 (4 + 8 + 128). Default 0.
<bit value>
Enable bits 3 and 4 in the enable register: STAT:OPER:ENAB 24
For example, with bit 3 (value 8) and bit 5 (value 32) set (and corresponding bits enabled), the query
returns +40.
A *CLS does not clear the enable register, but does clear the event register.
STATus:OPERation:NTRansition <value>
STATus:OPERation:NTRansition?
STATus:OPERation:PTRansition <value>
STATus:OPERation:PTRansition?
Sets and queries the value of the NTR (Negative-Transition) and PTR (Positive-Transition) registers.
These registers serve as a polarity filter between the Operation Condition and Operation Event
registers.
When a bit in the NTR register is 1, then a 1-to-0 transition of the corresponding bit in the Operation
Condition register causes that bit in the Operation Event register to be set.
When a bit in the PTR register is 1, then a 0-to-1 transition of the corresponding bit in the Operation
Condition register causes that bit in the Operation Event register to be set.
The STATus:PRESet command sets all bits in the PTR registers and clears all bits in the NTR registers.
Parameter Typical Return
Decimal sum of the bits in the register, default 0. For example, to enable bit 2 (value 4), bit 3 (value 8), and bit
7 (value 128), use decimal sum 140 (4 + 8 + 128). Default 0.
<bit value>
Enable bits 3 and 4 in the NTR register: STAT:OPER:NTR 24
If the same bits in both NTR and PTR registers are set to 1, then any transition of that bit at the
Operation Condition register sets the corresponding bit in the Operation Event register.
If the same bits in both NTR and PTR registers are set to 0, then no transition of that bit at the
Operation Condition register can set the corresponding bit in the Operation Event register.
The value returned is the binary-weighted sum of all bits set in the register.
