[SOURce:]VOLTage[:LEVel]:MODE FIXed|STEP
[SOURce:]VOLTage[:LEVel]:MODE?
Sets the trigger transient mode for voltage settings.
Parameter Typical Return
FIXed|STEP FIX
Set the trigger function control of the AC voltage to STEP:
VOLT:MODE STEP
Specifying FIX (default) disables the trigger function; specifying STEP enables it.
The *RST command sets this parameter to FIXed.
[SOURce:]VOLTage:OFFSet[:IMMediate] <value>|MINimum|MAXimum [,<low_limit>|MINim-
um|MAXimum,<high_limit>|MINimum|MAXimum]
[SOURce:]VOLTage:OFFSet[:IMMediate]? [MINimum|MAXimum]
[SOURce:]VOLTage:OFFSet:TRIGgered <value>|MINimum|MAXimum
[SOURce:]VOLTage:OFFSet:TRIGgered? [MINimum|MAXimum]
Sets the immediate or triggered DC voltage in VDC, and optionally sets the soft limits for the
immediate DCvoltage.
Parameter Typical Return
DC mode 155 V range: -222.5 to +222.5 V
DC mode 310 V range: -445.0 to +445.0 V
AC+DC mode: The total voltage must be within the voltage limits, and the AC+DC peak must be between -445
and +445 V.
+1.50000E+02
Set the immediate DCvoltage to 150 V:
VOLT:OFFS 150
This command takes one or three arguments. You cannot have a low or high limit without the other.
This command applies to DC and AC+DC.
Error message +160 is generated if the IMMediate voltage is set outside the MIN/MAX limits, and error
message +161 is generated if the TRIGgered voltage is set outside the MIN/MAXlimits.
Voltage units (MV, V, KV) are supported.
The *RST command sets this parameter to 0.
