Step Description Front Panel SCPI
1 Select the low voltage
range.
[Menu]>System>Admin>Cal>DC
Then select the Low range.
CAL:VOLT:OFFS 219
2 Select the first voltage
calibration point.
Select Next. The information field should indicate:
Enter P1 measured data
CAL:LEVP1
*OPC?
3 Measure the output
voltage with the DMM
and enter the data.
Enter the measurement from the external DMM in
the Measured Data field. Press [Select] or
[Enter] when done.
CAL:DATA <data>
4 Repeat steps 2 and 3 for calibration point 2 (P2). Note that the SCPI command in step 2 will change to
CAL:LEV P2, and the front-panel message will read Enter P2 measured data.
5 Select Next or press Back to finish this part of the calibration.
DC Voltage High Range
Use the same DMM configuration as for the DC Voltage Low Range calibration.
Step Description Front Panel SCPI
1 Select the high voltage
range.
[Menu]>System>Admin>Cal>DC
Then select the High range.
CAL:VOLT:OFFs438
2 Select the first voltage
calibration point.
Select Next. The information field should
indicate:
Enter P1 measured data
CAL:LEVP1
*OPC?
3 Measure the output
voltage with the DMM
and enter the data.
Enter the measurement from the external DMM
in the Measured Data field. Press [Select] or
[Enter] when done.
CAL:DATA <data>
4 Repeat steps 2 and 3 for calibration point 2 (P2). Note that the SCPI command in step 2 will change to
CAL:LEV P2, and the front-panel message will read Enter P2 measured data.
5 Select Next or press Back to finish this part of the calibration.
AC Voltage Low Range
Use the same physical configuration that you used for DCVoltage calibration, but configure the 3458A
for AC voltage measurements. You can use the following SCPI commands (or their front-panel
equivalents) to configure the DMM:
*RST
SETACV ANA, RANGE AUTO, ACBAND 20, 2E6
ACV
