Connecting the Load Cables
Possible Electric Shock
Before making any load or sense connections be sure to turn the POWER
switch off and remove the power plug from an outlet or turn off the circuit
breaker of switchboard.
When the power switch is turned off while the output is on, residual voltage
still remains at the output terminals.
Do not touch the output terminal block for at least 20 seconds after the
power switch is tuned off.
There is a danger of electric shock. Do not use the terminal block with the
terminal cover removed.
In DC mode, L is at positive potential and N is at negative potential when
setting the positive value. The opposite is true when setting the negative
value.
1îîGetting Started
52 Keysight AC6800B Series Operating and Service Guide
