Keysight Technologies B1500A User Manual

4- 14 Keysight B1500A User’s Guide, Edition 14
Specifications
Hardware
Table 4-7 Voltage range, resolution, and accuracy (high speed ADC)
Table 4-8 Current range, resolution, and accuracy (high speed ADC)
Range
Force
resolution
Measurement
resolution
Force accuracy
±(%+mV)
a
a. ±(% of output/measured value + offset value in mV)
Measurement accuracy
±(%+mV)
a
Maximum
current
±2 V 100 V100 V ±(0.018 + 0.4) ±(0.01 + 0.7) 1 A
±20 V 1 mV 1 mV ±(0.018 + 3) ±(0.01 + 4) 1 A
±40 V 2 mV 2 mV ±(0.018 + 6) ±(0.015 + 8) 500 mA
±100 V 5 mV 5 mV ±(0.018 + 15) ±(0.02 + 20) 125 mA
±200 V 10 mV 10 mV ±(0.018 + 30) ±(0.035 + 40) 50 mA
Range
Force
resolution
Measurement
resolution
Force accuracy ±(%+A+A)
a
a. ±(% of output/measured value + fixed offset in A + proportional offset in A), Vo is the output
voltage in V.
Measurement accuracy
±(%+A+A)
a
Maximum
voltage
±1 nA 50 fA 50 fA ±(0.1+3E-13+Vo1E-15) ±(0.25+3E-13+Vo1E-15) 200 V
±10 nA 500 fA 500 fA ±(0.1+3E-12+Vo1E-14) ±(0.25+2E-12+Vo1E-14) 200 V
±100 nA 5 pA 5 pA ±(0.05+3E-11+VoE-13) ±(0.1+2E-11+Vo1E-13) 200 V
±1 A 50 pA 50 pA ±(0.05+3E-10+VoE-12) ±(0.1+2E-10+Vo1E-12) 200 V
±10 A 500 pA 500 pA ±(0.05+3E-9+Vo1E-11) ±(0.05+2E-9+Vo1E-11) 200 V
±100 A 5 nA 5 nA ±(0.035+15E-9+VoE-10) ±(0.05+2E-8+Vo1E-10) 200 V
±1 mA 50 nA 50 nA ±(0.04+15E-8+Vo1E-9) ±(0.04+2E-7+Vo1E-9) 200 V
±10 mA 500 nA 500 nA ±(0.04+15E-7+VoE-8) ±(0.04+2E-6+Vo1E-8) 200 V
±100 mA 5 A5 A ±(0.045+15E-6+VoE-7) ±(0.1+2E-5+Vo1E-7)
b
b. 200 V (Io  50 mA), 100 V (50 mA < Io  125 mA), 40 V (125 mA < Io  500 mA),
20 V (500 mA < Io  1 A), Io is the output current.
±1 A 50 A50 A ±(0.4+3E-4+VoE-6) ±(0.5+3E-4+Vo1E-6)
