Keysight B1500A User’s Guide, Ed ition 14 4- 23
Specifications
Hardware
• DC bias function
•DC bias
Range: 0 to ± 25 V
Resolution: 1 mV
Accuracy: ± (0.5 % + 5.0 mV) at the measurement port of the MFCMU or
the MFCMU cable (1.5 m or 3.0 m)
• Maximum DC bias current, supplemental characteristics:
• Output impedance: 50 , typical
•DC bias monitor
Range: 0 to ± 25 V
Accuracy (open load): ± (0.2 % of reading + 10 mV) at the measurement
port of the MFCMU or the MFCMU cable (1.5 m or 3.0 m)
• Sweep characteristics
• Available sweep parameters: DC bias voltage, oscillator level, frequency
• Sweep type: linear, log
• Sweep mode: single, double
• Sweep direction: up, down
• Number of measurement points: maximum 1001
Impedance range () Maximum DC bias current (A)
50
10
10
-3
100
10
10
-3
300
10
10
-3
1
10
3
1
10
-3
3
10
3
1
10
-3
10
10
3
100
10
-6
30
10
3
100
10
-6
100
10
3
10
10
-6
300
10
3
10
10
-6
