Table 4-11 Parameters E
POSC
, Z
OSC
Vosc is oscillator level in mV.
Table 4-12 Parameters E
PL
, Y
OL
, Z
SL
f is frequency in MHz. If measurement cable is extended, open compensation,
short compensation, and load compensation must be performed.
Table 4-13 Parameters Y
OSC
, Y
O
, E
P
, Z
S
Vosc is oscillator level in mV.
Oscillator level
Vosc mV
E
POSC
%Z
OSC
m
125 < Vosc  250 0.03(250/Vosc-1) 5(250/Vosc-1)
64 < Vosc  125 0.03(125/Vosc-1) 5(125/Vosc-1)
32 < Vosc  64 0.03(64/Vosc-1) 5(64/Vosc-1)
Vo s c  32 0.03(32/Vosc-1) 5(64/Vosc-1)
Cable length
E
PL
%Y
OL
nS Z
SL
m
1.5 m 0.02+3f/100 750f/100 5.0
3 m 0.02+5f/100 1500f/100 5.0
Frequency f Hz
Y
OSC
nS Y
O
nS E
P
%Z
S
m
1k  f  200k 1(125/Vosc-0.5) 1.5 0.095 5.0
200k < f  1M 2(125/Vosc-0.5) 3.0 0.095 5.0
1M < f  2M 2(125/Vosc-0.5) 3.0 0.28 5.0
2M < f 20(125/Vosc-0.5) 30.0 0.28 5.0
