3- 16 Keysight B1500A User’s Guide, Edition 14
Installation
Installing Accessories
Table 3-4 To Connect Connector Plate
Cables
Connector
Plate
B1500A Terminals
Keysight 16493J Interlock Cable, 3 m or 1.5 m Intlk Interlock
Keysight 16493L GNDU Cable, 3 m or 1.5 m GNDU GNDU
Keysight 16493K
a
Kelvin Triaxial Cable, 3 m
or 1.5 m, for the Kelvin connection
16495F provides the inputs 1 to 12 (6 Kelvin).
16495H provides the inputs 1 to 6 (3 Kelvin).
16495J provides the inputs 1 to 8 (4 Kelvin).
a. Use Keysight 16494B Kelvin Triaxial Cable to connect to Keysight E5250A
Low Leakage Switch Mainframe or the connector plate for Keysight 4142B
Modular DC Source/Monitor by the Kelvin connection.
odd number
SMU
Force
even number Sense
Keysight 16494A Triaxial Cable, 3 m or 1.5 m,
for non-Kelvin connection
16495H provides the inputs 1 to 6.
16495J provides the inputs 1 to 8.
odd number
or
even number
SMU Force
Keysight 16493P SPGU Cable, 3 m or 1.5 m
16495H provides the inputs 7 to 12.
16495J provides the inputs 9 to 12.
odd number
or
even number
SPGU Output 1
Output 2
Keysight N1300A CMU Cable
b
, 3 m or 1.5 m
16495H provides the inputs 7 to 12.
16495J provides the inputs 9 to 12.
b. To extend the four-terminal pair (4TP) connection to the connector plate
inputs, connect the Hcur and Hpot cables together and the Lcur and Lpot
cables together by using the BNC T-type adapter (female-female-male, Key-
sight part number 1250-2405), then connect them to the connector plate
inputs. To extend the 4TP connection to the DUT interface, connect the cables
to the connector plates input connectors individually, and connect the Hcur
and Hpot terminals together and the Lcur and Lpot terminals together on the
DUT interface. See Figure 3-21.
It is ok to leave open the ground wire extended from the CMU cable.
odd number
or
even number
CMU
Hcur/Hpot
Lcur/Lpot
