Optional Items:
The following adapter and the cable are required for configuring the 40 A solution by
using two HCSMU modules. The configuration for 40A solution is introduced in the
appendix section.
Optional accessories (for 40A configuration only)
●
1 X 16493S Opt 021 Dual HCSMU Combination Adapter
●
1 X 16493S Opt 021 cable
16493S Opt 021
(40 A option)
16493S Opt 021 Cable
(40 A option)
Note:
Digital I/O cable shown in figure 2-5 is used for controlling the N1259A Option 300
Module Selector.
Since the Module Selector is not used in this section, there is no need for connect-
ing this cable at the moment.
However Module Selector is handled in the appendix section where the N1259A
Option 300 Module Selector is used for automatically switching between HCSMU
and HVSMU.
16493G Digital I/O Cable
(Optional for N1259A Opt 300)
Figure 2-5. Digital I/O Cable
Figures 2-4. Cables used for 40 A configuration
