General Idea of measurement using the EasyEXPERT software
Figure 3-1 shows the general idea of measurement using the EasyEXPERT Applica-
tion Test Library.
The idea is straight forward and easy to use;
Step 1. Choose device type or application category from the Category field.
Or, just from step 1` where your unique setup has been saved in My Favorite
Setup field, and you can just start from here by just selecting a setup icon
and skip step 2 and go to step 3 Measure.
Step 2. Select Application Test definition from the Library field.
Step 3. Measurement buttons for Single measure, Append measure and Repeat
measure.
Then measurement data pops up, and the data can be saved in Results area
automatically.
Chapter 3 uses the full features of these easy to use EasyEXPERT test environ-
ments.
EasyEXPERT has many default applications for basic measurements. You can meas-
ure the device easily, by simply selecting the desired application. With an illustrative
user interface, you can intuitively modify the parameters to suit your DUT.
Figure 3-1. General Idea of measurement using the EasyEXPERT software.
1
Choose device or
Application Category
3
Press Measure button
and Meas. starts
Select Application
Test
2
1`
Or, select from
My Favorite setup
Displays meas. data in real time
and shows parameters at the same
time
To Next Page
