Appendix C SCPI Commands
108 Series E4360 User’s Guide
SCPI Command Description
:ACQuire
[:IMMediate] [(@chanlist)
Triggers the measurement immediately
:DELay <NRf> [,(@chanlist) Specifies a time delay for the measurement trigger
:SOURce BUS | PIN<n> | TRAN<n> [,(@chanlist)]
Sets the measurement trigger source
:DLOG
[:IMMediate] [(@chanlist)]
Triggers the datalog immediately
:SOURce
BUS|DLOG<n>|PIN<n>|TRAN<n>[,(@chanlist)]
Sets the datalog trigger source
:PIN<3-7>
:SOURce
BUS|ACQ<n>|DLOG<n>|DWEL<n>|TRAN<n>
Selects the trigger source for the digital I/O pin
Common Commands
Command
Description
Command
Description
*CLS Clear status *RST Reset
*ESE <NRf>
Standard event status enable
*SAV <NRf>
Saves an instrument state
*ESR? Return event status register *SRE <NRf> Set service request enable register
*IDN? Return instrument identification *STB? Return status byte
*OPC Enable "operation complete" bit in ESR *TRG Trigger
*OPT? Return option number *TST? Selftest
*RCL <NRf> Recalls a saved instrument state *WAI Pauses additional command processing
*RDT? Return output channel descriptions until all device commands are done
*RST Settings
These settings are set by the *RST (Reset) command
CAL:STAT OFF [SOUR:]LIST:SAS:VOC 65 E4361A; 130 E4362A
[SOUR:]CURR 0 [SOUR:]LIST:STEP AUTO
[SOUR:]CURR:MODE FIX [SOUR:]LIST:TERM:LAST OFF
[SOUR:]CURR:PROT:LEV 1.1 X MAX MEM:TABL:CURR 0
[SOUR:]CURR:SAS:IMP 0.8 X MAX MEM:TABL:VOLT 0
[SOUR:]CURR:SAS:ISC MAX OUTP OFF
[SOUR:]CURR:SAS:MODE IMM OUTP:COUP OFF
[SOUR:]CURR:TABL:OFFS 0 OUTP:PROT:COUP OFF
[SOUR:]DIG:OUTP:DATA 0 TRIG:ACQ:DEL 0
DISP:ENAB ON TRIG:ACQ:SOUR BUS
DISP:VIEW METER1 TRIG:TRAN:SOUR BUS
INIT:CONT:TRAN OFF TRIG:PIN:SOUR NONE
[SOUR:]LIST:COUN 1 [SOUR:]VOLT 0
[SOUR:]LIST:DWEL 0.025 [SOUR:]VOLT:PROT MAX
[SOUR:]LIST:SAS:IMP 6.528 E4361A; 3.264 E4362A [SOUR:]VOLT:SAS:VMP 0.8 X MAX
[SOUR:]LIST:SAS:ISC 8.7 E4361A; 5.1 E4362A [SOUR:]VOLT:SAS:VOC MAX
[SOUR:]LIST:SAS:VMP 60 E4361A; 120 E4362A [SOUR:]VOLT:TABL:OFFS 0
