If the measured frequency is too high, you are finding too many edges and should increase the
Noise Rejection level. If the measured frequency is too low or nonexistent, decrease the
measurement range. In either case, it is preferable to select the lowest fixed measurement range
that can still measure the signal.
CWA Configuration
This section describes typical CWAconfiguration. To configure CWA (usually after pressing a
CWASetup softkey):
1. Press the Sync Source key and select the channel whose zero crossings will define cycles for
CWA.
2. Press Noise Rejection and select the amount of hysteresis to add in order to prevent the
signal from falsely counting extra edges on a noisy or distorted signal.
3. If your signal is raised or lowered by a DC offset, press the Sync Offset softkey and enter the
amount by which the signal is offset.
4. Press the Meas Mode softkey. Choose AC to measure the AC content of the signal, DC for
the DC content, and AC+DC for the combined AC and DC content. This applies only to
power measurements, such Apparent Power and Real Power.
5. Press Meas Window and specify the length of the CWA measurement window. The actual
window will be slightly longer, as described in the Theory of Operation, above.
6.
If necessary, Increase the CWA Window to measure low frequencies, as shown below.
CWA Window Min. Measurable Freq.
50 ms 200 Hz
100 ms 100 Hz
Default 200 ms 45 Hz
500 ms 20 Hz
1 s 10 Hz
2 s 5 Hz
5 s 2 Hz
10 s 1 Hz
20 s 0.5 Hz
Keysight IntegraVision PA2200 Series Power Analyzers Operating and Service Guide111
