Softkey Menu Overview
The softkey menus associated with front-panel keys are shown in the table below.
Section Key Softkeys
Horizontal
Horiz Fine, Time Ref
Search Search, Settings, Thresholds
Navigate Navigate, Event
Run Control
Default Setup
Undo Default Setup, Default Setup, Default GUI Layout,
FactoryDefault, Secure Erase
Auto Scale
Undo Autoscale, Arrange
Trigger
Trigger Trigger Type, Source, Slope
Mode/Setup Trigger Mode, Noise Reject
Measure
Cursors
Mode, Measurement
Measure
Source, Type, Add Measurement, Settings,
Clear Meas, Statistics
Waveform
Acquire
Acq Mode,
Datalog
, Zero Compensation
Label
Channel, New Label, Apply New Label, Library,
Reset Library, Annotation
Display
Clear Display, Grid Intensity, Screen Layout, Phasor
File
Save/Recall
Save, Recall, Email, Defaults, Press to Save
Print
Print to, Options, Palette, Network Setup, Press to Print
Tools Utility
I/O
,
File Explorer
,
User Options
, Service,
Quick Action
Quick Action
Action
Analyze Analysis
,
Source
,
Meas Window
,
CWASetup
Help
Getting Started, About IntegraVision
Math/Reference
Math
Display Math, Operator, Source 1, Source 2
Ref
Display Ref, Source, Save to, Clear, Skew, Display Info
Vertical 1, 2, 3, 4
Signals, Coupling, Antialiasing, Current Input, Ranging,
Filter
Wiring(PA2201A) Channel 1, Channel 2, Phase Names,
Channel Skew
Wiring(PA2203A)
Channel 1, Channel 2, Channel 3, Channel 4,
Phase Names,
Channel Skew
Filter(PA2203Aonly)
Channel 1, Channel 2, Channel 3, Channel 4
Phasor
(PA2203Aonly)
Phasor Diagram, Source, Volts /, Amps /
38 Keysight IntegraVision PA2200 Series Power Analyzers Operating and Service Guide
