Keysight Technologies IntegraVision PA2201A Series

Group Measurements
The following measurements are available for wiring groups, as shown below.
Measurement 1P-3W-2M 3P-3W-2M 3P-3W-3M 3P-4W-3M
VDC (DC Only)
• • • •
ADC (DC Only)
• • • •
Vrms (AC Only)
• • • •
Arms (AC Only)
• • • •
Vrms (AC+DC)
• • • •
Arms (AC+DC)
• • • •
Real Power (AC)
• • •
Real Power (AC+DC)
• • • •
Real Power (DC)
• • •
Rectified Mean Voltage
• • • •
Rectified Mean Current
• • • •
Apparent Power (AC)
• • •
Apparent Power (AC+DC)
• • • •
Reactive Power (AC)
• • •
Reactive Power (AC+DC)
• • • •
Power Factor (AC)
• • •
Power Factor (AC+DC)
• • • •
Max Voltage
• • • •
Min Voltage
• • • •
Max Current
• • • •
Min Current
• • • •
Power Angle (AC)
• • •
Power Angle (AC+DC)
• • • •
