11 Use the six softkeys (two shown here) to
navigate through the menus. Press the
round [Back] key to return to the previous
menu.
12 Press the power switch to turn the instru-
ment on.
13 Use the two USB ports to save and load
files.
Tilt the Instrument for Easy Viewing
Move the support feet on the bottom of the front of the instrument (both sides) into the tilted
position as shown below.
24 Keysight IntegraVision PA2200 Series Power Analyzers Operating and Service Guide
