Ax + B
The Ax + B transform applies a gain (A) and offset (B) to an input source. For example, the image
below shows an Ax+B transform applied to a sine wave, with A=1 and B=0 (the default values).
Note that the Offset indicator of 7.00000 A displayed above the Gain (A) softkey refers to the
waveform's display offset and not the offset of the math transform.
150 Keysight IntegraVision PA2200 Series Power Analyzers Operating and Service Guide
