The image below shows the traces arranged by group. Note that all voltages are set to the same
vertical scale, based on the largest voltage. This scaling principle also applies to current and
power, and it enables you to quickly detect imbalances across channels. If a signal is relatively
small, you always have the option to select the appropriate channel and adjust its scale
individually.
