Keysight M8000 Series of BER Test Solutions Installation Guide 47
Installing Modules 2
The following figure displays the M9536A Embedded Controller installed in
slot 1 of the M9514A AXIe chassis.
Figure 31 M9536A embedded controller installed in M9514A AXIe chassis
You do not need to manually establish any external PCIe/USB or LAN connection
between the M9536A or M9537A AXIe Embedded Controller and M8020A
because this controller communicates with the ASM through the chassis
backplane.
You do not need to manually install any operating system or drivers for this
module. The Windows 7 (64 bit) operating system is pre-installed based on your
choice, and the module is ready to be used as the host computer.
