Keysight CXG, EXG, and MXG X-Series Signal Generators Service Guide 434
Functional Tests
Leveled Output Power
b. Select a power meter channel (if applicable).
c. Use the arrow keys to enter the frequency at which to measure the
power.
9. Measure the output power level.
10.Repeat steps 6 through 9 to measure power at each of the frequencies
listed in Table 17-2.
11.Confirm that the measured power levels are within the limits listed in the
table.
Limit values are due to power meter uncertainty.
Table 17-2 Leveled Output Power Limits
N5171B/81B Output Power
Frequency (MHz) Amplitude (dBm) Limits (dB)
100 kHz 7 ±0.6
1 MHz 7 ±0.8
50 MHz 7 ±0.8
125 MHz 7 ±0.8
275 MHz 7 ±0.8
338 MHz 7 ±0.8
425 MHz 7 ±0.8
538 MHz 7 ±0.6
675 MHz 7 ±0.6
850 MHz 7 ±0.6
1075 MHz 7 ±0.6
1350 MHz 7 ±0.6
1700 MHz 7 ±0.6
2150 MHz 7 ±0.6
2700 MHz 7 ±0.6
3400 MHz 7 ±0.6
4300 MHz 7 ±0.6
5400 MHz 7 ±0.6
