Keysight FieldFox A Series User Manual

Keysight N9927-90001 User’s Guide 101
NA (Network Analyzer) Mode
NA Mode Settings
Sweep Time
The fastest possible sweep time is always used as the default setting. Use the
Min Swp Time setting to slow the sweep time when measuring long lengths of
cable. Learn more at the FieldFox Supplemental Online Help:
http://na.support.keysight.com/fieldfox/help/SupHelp/FieldFox.htm
The actual sweep time is shown on the FieldFox screen. See the Screen Tour
on “Screen Tour” on page 41. To increase the sweep time, enter a value that is
higher than the actual sweep time. The increase will not be exactly the amount
that you enter, as the actual sweep time is the composite of many factors.
How to set Sweep Time
—Press Sweep 3
.
—Then Min Swp Time
.
— Enter a value using the numeric keypad.
— Press a multiplier key. Learn about multiplier abbreviations in “Multiplier
Abbreviations” on page 43.
Triggering
External triggering (NA and SA modes ONLY) allows you to initiate a sweep
when an external DC voltage is sensed at the Ref In/Trig In connector on the
FieldFox top panel. See External Triggering for SA Mode in “Triggering” on
page 172.
Trigger Source
—Press Sweep 3
—Then Trigger
—Then Trig Source
— Then choose from the following:
—Internal
Sweeps are initiated by the FieldFox internal circuitry. When
Sweep is set to Continuous, a new sweep begins automatically when
the previous sweep ends.
—External
A sweep is initiated on the rising or falling edge of an external
TTL signal at the Ref In/Trig In connector on the FieldFox top panel.
——When the FieldFox is armed for an external trigger signal, Wait
is annotated on the display.
——A sweep can NOT be initiated by an external signal while a
sweep is in progress.
Measurement speed specifications do NOT apply in Temperature Control
Mode. Learn more in
“Temperature Control Mode” on page 31.
