Keysight N9927-90001 User’s Guide 267
Over–the–Air Measurements (OTA) – LTE FDD Option 370 and 5GTF Option 377 (CPU2
Only)
Using OTA (Options 370 – LTE FDD and 377 – 5GTF)
Using OTA (Options 370 – LTE FDD and 377 – 5GTF)
OTA enables you to do the following:
Measure and display one component carrier (CC) with multiple cells or multiple cells with
multiple component carriers (CCs)
ab
a. When multiple component carriers are selected, the results of the component carrier
(CC) with the highest power is displayed.
b. LTE FDD can measure and display multiple cells. 5GTF only has the ability to measure
and display a single cell.
Four Display Types:
— Bar chart
—Table
—Strip Chart
— Spectrum
Color Coded Display Types:
— Specify high and low power with
color bars
Flexible Data Sorting:
— LTE FDD: Sort Cells, component
carriers (CCs), Frequency, RSRP,
RSRQ, RSSI, PSS, SSS, and SINR
scan results displayed by low to
high, or high to low, or Auto (no
order is involved)
— 5GTF: Sort Carrier Info, PCI (aka Cell
IDs), Power, PSS, SSS, Sync
Correlation (%) scan results
displayed by low to high, or high to
low, or Auto (no order is involved)
Data Logging. Record GPS stamped data measurements
— Define measurement interval by time
or distance
— Show results in Table or Bar Chart
— Display files (KML) on Google Maps
or Google Earth
