432 Keysight N9927-90001 User’s Guide
Channel Scanner (Option 312)
How to Set Up Channel Scanner
— All Channel Scanner mode Antenna and Cable files are saved and recalled
as *.csv files, which allows them to also be read by spreadsheet programs.
— The FieldFox can also read *.ANT (Antenna) files that were created from
older Keysight Spectrum Analyzers.
— Channel Scanner Mode cable or antenna (*.csv or *.ANT) files can NOT be
edited in Data Link software.
How to create a Cable file from an S21 (NA mode) or an Insertion Loss
(CAT mode) measurement
1. Measure the S21 or Insertion Loss of a cable. In NA mode, select either
LogMag, Linear, or VSWR formats.
2. Use Manage Folders to change the active folder to CABLES. Learn how in
“Manage Folders” on page 554.
3. While in NA mode, save the measurement as a *.csv file. Learn how in “How
to Save a File” on page 544.
4. In Channel Scanner mode, select Corrections
, then recall the *.csv file for
correction.
