3 Spectrum Analyzer Mode
3.5 ACP Measurement
Max Num of Offsets
Sets the max number of offsets: either 6 or 12.
This setting applies only to SCPI operations. To specify the same behavior as that of
the previous version, selecting 6 offsets is recommended. If you select 12 offsets, the
results returned by the :READ|:FETCh queries increase accordingly.
Example:
When you select 6 offsets, querying the offset state returns 6 values, as below.
-> :SENSe:ACPower:OFFSet:LIST:STATe?
<- 1,0,0,0,0,0
When you select 12 offsets, sending the same query returns 12 values, as below.
-> :SENSe:ACPower:OFFSet:LIST:STATe?
<- 1,0,0,0,0,0,0,0,0,0,0,0
If your program depends on the number of returned values, you should select 6
offsets, or else change your program.
Remote
Command
[:SENSe]:ACPower:OFFSet:MAXNumber NUM6 | NUM12
[:SENSe]:ACPower:OFFSet:MAXNumber?
Example
:ACP:OFFS:MAXN NUM12
:ACP:OFFS:MAXN?
Preset
NUM6
State Saved Saved in instrument state
Range 6|12
Limit Test
Turns limit checking for each offset On or Off. The limits may be specified in the
Offset menu, for each offset, both sides of the carrier. For results that fail the limit, a
red F is appended. In the Combined view, the bar turns red.
Remote Command
:CALCulate:ACPower:LIMit:STATe OFF | ON | 0 | 1
:CALCulate:ACPower:LIMit:STATe?
Example
:CALC:ACP:LIM:STAT OFF
:CALC:ACP:LIM:STAT?
Preset
SA
OFF
WCDMA, LTEAFDD, LTEATDD, 5G NR, MSR
ON
1010 Spectrum Analyzer Mode User's &Programmer's Reference
