3 Spectrum Analyzer Mode
3.5 ACP Measurement
3.5.1 Measurement Results for n = 1, or no Index Specified
Mode = SA, Radio Std = None, Number of carriers = 1, Only Offset A is On
Returns 3 comma-separated values that correspond to:
# Item Unit, if
any
1 Reference carrier power
2 Lower-adjacent channel power of the trace specified by "Measure Trace" on
page 1754
dBc
3 Upper-adjacent channel power of the trace specified by "Measure Trace" on
page 1754
dBc
The values are in the current Y Axis Unit of the instrument
Meas Method = FAST
See also "Meas Method" on page 970
For the trace specified by "Measure Trace" on page 1754, returns 5 comma-
separated scalar results in the following order:
# Item Result Unit, if any
1 Reference carrier Absolute power dBm
2 Lower offset A Absolute power dBm
3 Upper offset A Absolute power dBm
4 Lower offset B Absolute power dBm
5 Upper offset B Absolute power dBm
Measurement Type = Total Power Reference
Conditions Results
Mode: LTEAFDD, LTEATDD,
5GNR, MSR
"Power Ref" on page 1056:
LRCarriers
LRSubblocks
MPCSubblock
MINSubbloc
For all other Power Ref settings,
see All other Modes row below
For the trace specified by "Measure Trace" on page 1754, returns comma-separated
scalar results in the following order:
# Item Unit, if any
1 0.0
2 Total carrier power dBm
3 Left Reference power dBm
4 Right Reference power dBm
874 Spectrum Analyzer Mode User's &Programmer's Reference
