3 Spectrum Analyzer Mode

3.3 Channel Power Measurement

The X-Axis settings and domain of a trace are also copied when it is exchanged with

another trace.

Remote

Command

For Swept SA Measurement (in SA Mode):

:TRACe:EXCHange TRACE1 | … | TRACE6, TRACE1 | … | TRACE6

For all other measurements:

:TRACe:<meas>:EXCHange TRACe1 | TRACe2 | TRACe3, TRACe1 | TRACe2 | TRACe3

where <meas> is the identifier for the current measurement

Note that the format of the :TRACe<n> parameter differs from that for the Swept SA Measurement

Example Exchange Trace 1 and Trace 2 and put both traces in Update=OFF, Display=ON:

:TRAC:EXCH TRACE1,TRACE2

Notes The command is of the form:

:TRACe:EXCHange <trace_1>,<trace_2>

Couplings Both traces are put in View (Update=Off, Display=On) after the exchange

Preset All Traces

Turns on Trace 1 and blanks all other traces. This is useful when you have many

traces on and you want to return to having only Trace 1 on the display. Does not

affect the trace type, detector or any other aspect of the trace system.

Remote Command

:TRACe[:<meas>]:PRESet:ALL

Example

:TRAC:PRES:ALL

Dependencies When Signal ID is on, this key is grayed-out

Clear All Traces

Clears all traces. Does not affect the state of any function or variable in the

instrument. Loads mintracevalue into all of the points for all traces, except traces

in Min Hold, in which case it loads maxtracevalue, even if Update = OFF.

Remote Command

:TRACe[:<meas>]:CLEar:ALL

Example

:TRAC:CLE:ALL

Dependencies When Signal ID is on, this key is grayed-out

3.3.10.6 Advanced

Contains controls for setting advanced trace functions of the instrument.

Spectrum Analyzer Mode User's &Programmer's Reference 711
