3 Spectrum Analyzer Mode

3.5 ACP Measurement

Conditions Results

# Item Unit, if any

11 Upper offset B - relative power dB

12 Upper offset B - absolute power dBm/Hz or dBm/MHz*

... ... ...

When "Max Num of Offsets" on page 1010 is 6, returns 28 results (Offset A-F: 28 = 4 + 4*6) and

when set to 12, returns 52 results (Offset A-L: 52 = 4 + 4 * 12)

*The unit is determined by "PSD Unit" on page 1063: DBMHZ or DBMMHZ

If any result is not available, -999.0 is returned

For SA Mode, the values are in the current Y Axis Unit of the instrument

3.5.2 Measurement Results for n = 2

–

For SA Mode, the values are in the current Y Axis Unit of the instrument

–

For MSR, LTE Advanced FDD/TDD, and 5G NR Modes, this trace includes only

outer offset results and their reference value(s)

Measurement Type = Total power reference

For the trace specified by "Measure Trace" on page 1754, returns comma-separated

scalar results in the following order:

# Item Result Unit, if any

1 Channel (1) Relative power dB

2 Channel (1) Absolute power dBm

3 Channel (2) Relative power dB

4 Channel (2) Absolute power dBm

... ... …

23 Channel (12) Relative power dB

24 Channel (12) Absolute power dBm

25 Lower offset A Relative power dB

26 Lower offset A Absolute power dBm

27 Upper offset A Relative power dB

28 Upper offset A Absolute power dBm

29 Lower offset B Relative power dB

30 Lower offset B Absolute power dBm

31 Upper offset B Relative power dB

Spectrum Analyzer Mode User's &Programmer's Reference 877
