3 Spectrum Analyzer Mode

3.5 ACP Measurement

Measurement Type = Total power reference

For the trace specified by "Measure Trace" on page 1754, returns (2 * Number of

Carriers) comma-separated scalar results in the following order:

# Channel Result Unit, if any

1 Channel (1) Relative power dB

2 Channel (1) Absolute power dBm

3 Channel (2) Relative power dB

4 Channel (2) Absolute power dBm

… ...

2 * Number of Carriers – 1 Channel (Number of Carriers) Relative power dB

2 * Number of Carriers Channel (Number of Carriers) Absolute power dBm

Measurement Type = Power spectral density reference

For the trace specified by "Measure Trace" on page 1754, returns (2 * Number of

Carriers) comma-separated scalar results in the following order:

# Channel Result Unit, if any

1 Channel (1) Relative power dB

2 Channel (1) Absolute power dBm/Hz or dBm/MHz*

3 Channel (2) Relative power dB

4 Channel (2) Absolute power dBm/Hz or dBm/MHz*

... ...

2 * Number of Carriers - 1 Channel (Number of Carriers) Relative power dB

2 * Number of Carriers Channel (Number of Carriers) Absolute power dBm/Hz or dBm/MHz*

*The unit is determined by "PSD Unit" on page 1063: DBMHZ or DBMMHZ

3.5.5 Measurement Results for n = 8

Only available in LTEAFDD, LTEATDD, 5GNR, MSR Modes

For the trace specified by "Measure Trace" on page 1754, returns scalar results in

the following order:

# Item Unit, if any

1 0.0

2 Total carrier power dBm

3 Reference Power #1 (See "Reference Power Result Details" on

page 881)

4 Reference Power #2 (See "Reference Power Result Details" on

880 Spectrum Analyzer Mode User's &Programmer's Reference
