6 Input/Output

6.10 Calibrator Control

Preset Unaffected by Mode Preset. Set to OFF by Restore Input/Output Defaults or Restore System Defaults-

>All

6.10.3 Cal Frequency

Lets you set the selected calibrator’s frequency.

Remote

Command

:SYSTem:CALibration:TUNE:FREQuency <freq>

:SYSTem:CALibration:TUNE:FREQuency?

Example Set source frequency to 150 MHz:

:SYST:CAL:TUNE:FREQ 150000000

Preset Unaffected by Mode Preset. Set to 1GHz by Restore Input/Output Defaults or Restore System

Defaults->All

Min/Max Depend on the selected calibrator

6.10.4 Cal Signal Type

Lets you set the selected calibrator’s signal type.

Remote Command

:SYSTem:CALibration:TUNE:TYPE CW | COMB

:SYSTem:CALibration:TUNE:TYPE?

Example

:SYST:CAL:TUNE:TYPE CW

:SYST:CAL:TUNE:TYPE?

Dependencies If the selected calibrator does not support a signal type, then that type is disabled in the dropdown

Changing the signal type to a disabled option generates an error

Preset Unaffected by Mode Preset. Set to CW by Restore Input/Output Defaults or Restore System Defaults-

>All

6.10.5 Cal Comb Spacing

Lets you set the calibrator’s comb spacing, when the signal type is COMB.

Remote Command

:SYSTem:CALibration:TUNE:SPACing <freq>

:SYSTem:CALibration:TUNE:SPACing?

Example Set comb spacing to 1 MHz:

:SYST:CAL:TUNE:SPAC 1000000

Dependencies Only appears when COMB is selected as "Cal Signal Type" on page 2521

If the selected calibrator does not support the Comb signal, attempting to set the spacing generates

an error

Spectrum Analyzer Mode User's &Programmer's Reference 2521
