3 Spectrum Analyzer Mode

3.3 Channel Power Measurement

Mode Radio Std Integ BW

WLAN 802.11a/g(OFDM/DSSS-OFDM) 20 MHz

802.11b 25 MHz

802.11n/ac/ax/be (20MHz) 20 MHz

802.11n/ac/ax/be (40MHz) 40 MHz

802.11n/ac/ax/be (80MHz) 80 MHz

802.11ax/be (80 MHz + 80 MHz) 80 MHz

802.11ac/ax/be (160 MHz) 160 MHz

802.11be (160 MHz + 160MHz) 160 MHz

802.11be (320MHz) 320 MHz

State Saved Saved in instrument state

Min/Max 100 Hz / Hardware Maximum Span

Backwards

Compatibility SCPI

[:SENSe]:CHPower:BWIDth:INTegration

PSD Unit

Sets the unit bandwidth for Power Spectral Density. The available units are dBm/Hz

(DBMHZ) and dBm/MHz (DBMMHZ).

Remote

Command

:UNIT:CHPower:POWer:PSD DBMHZ | DBMMHZ

:UNIT:CHPower:POWer:PSD?

Example

:UNIT:CHP:POW:PSD DBMMHZ

:UNIT:CHP:POW:PSD?

Couplings When the PSD unit is changed, the response to :MEAS|READ|FETCH:CHP1? also changes by the

PSD unit basis (either dBm/Hz or dBm/MHz)

Preset WLAN mode or SA mode with WLAN radio standard: DBMMHZ

Otherwise: DBMHZ

State Saved Saved in instrument state

Range dBm/Hz | dBm/MHz

IF Gain

Sets IF Gain to Auto, Low Gain or High Gain. These settings affect sensitivity and IF

overloads.

Remote Command

[:SENSe]:CHPower:IF:GAIN[:STATe] ON | OFF | 1 | 0
