Keysight N9010B EXA Signal Analyzer Service Guide 413
Replaceable Parts
Hardware
Figure 14-11 RF Area - RF/Microwave Instruments with
Options B40, MPB, or DP2 (switch detail)
Table 14-13
Item Description Keysight Part Number
5SW1 Coaxial Switch (Options B40, MPB, or DP2) N1810-60069
6SW2 Coaxial Switch (Options B40, MPB, or DP2) N1810-60069
7 AT1 Fixed Attenuator, 6 dB 08493-60026
W10 Cable Assembly, J1 to A9 Input (semi-rigid) N9020-20141
W31 Cable Assembly, SW2 Center Port to A11J3 (Semi-rigid) E4410-20161
W32 Cable Assembly, SW2 Port 2 to A12J2 (Semi-rigid) E4410-20163
W33 Cable Assembly, SW1 Port 2 to A12J1 (Semi-rigid) E4410-20165
W34 Cable Assembly, SW1 Center Port to A13J9 (Semi-rigid) E4410-20164
W35 Cable Assembly, AT1 to SW1 Port 1 (Semi-rigid) N9020-20210
