Keysight NFA Series User Manual

Chapter 2 87
Test Descriptions
Measurement Jitter
Step 9. Convert the linear standard deviation to Log
10
using
10 * LOG
10
(1+ standard deviation
Lin
)
to give the standard deviation for Y-Factor results with no Averaging.
Enter the result into the Test Record ensuring that the measured value
is within its published specification.
Example:
Standard Deviation = 10 * LOG
10
(1+ standard deviation
Lin
)
=10 * LOG
10
(1+ 0. 011071
Lin
)
= 0.0478dB
Table 2-24 Measurement Jitter Test Worksheet
Y-Factor
Reading
(Lin)
Y-Factor
Reading
(Lin)
Y-Factor
Reading
(Lin)
Y-Factor
Reading
(Lin)
Y-Factor
Reading
(Lin)
Y-Factor
Reading
(Lin)
Y-Factor
Reading
(Lin)
Y-Factor
Reading
(Lin)
Y-Factor
Reading
(Lin)
Y-Factor
Reading
(Lin)
1-10 11-20 21-30 31-40 41-50 51-60 61-70 71-80 81-90 91-100
