Test Descriptions

Input VSWR

Test Description

The Input VSWR test measures the worst case VSWR over each of the

specified frequency bands detailed in the Table 2-1 on page 22. The test

measures VSWR directly from the Network Analyzer, however the

conversion below can be used if measuring return loss.

VSWR or voltage standing wave ratio can be calculated from the

reflection coefficient using the following equation:

Equation 2-1

Table 2-5 VSWR Frequency Test Bands

N8972A N8973A N8974A N8975A

PART 1

CAL VNA 10 MHz - 1.5

OR 3.0 GHz

••••

PART 2

TEST VSWR

10 MHz - 500 MHz

••••

PART 3

TEST VSWR

500 MHz -1000 MHz

••••

PART 4

TEST VSWR

1000 MHz -1500 MHz

••••

VSWR

1 rho+[]

1 rho–[]

-----------------------

VSWR

1 ρ+[]

1 ρ–[]

-----------------=





≅=
