Keysight NFA Series - Frequency Accuracy Test Record

132 Appendix C
Model N8974A: Test Records
Frequency Accuracy Test Record
Frequency Accuracy Test Record
Frequency
(MHz)
Frequency
Span
(MHz)
Selected
Bandwidth
(MHz)
Resolution
(MHz)
Measured
Center
Frequency
(MHz)
Specification Pass/Fail
14.00 8.00 4.00 ± 10 kHz ± 100 kHz + x
30.00 8.00 4.00 ± 10 kHz ± 100 kHz + x
60.00 8.00 4.00 ± 10 kHz ± 100 kHz + x
100.00 8.00 4.00 ± 10 kHz ± 100 kHz + x
300.00 8.00 4.00 ± 10 kHz ± 100 kHz + x
600.00 8.00 4.00 ± 10 kHz ± 100 kHz + x
1000.00 8.00 4.00 ± 10 kHz ± 100 kHz + x
1500.00 8.00 4.00 ± 10 kHz ± 100 kHz + x
2000.00 8.00 4.00 ± 10 kHz ± 100 kHz + x
4000.00 8.00 4.00 ± 10 kHz ± 400 kHz + x
5000.00 8.00 4.00 ± 10 kHz ± 400 kHz + x
6000.00 8.00 4.00 ± 10 kHz ± 400 kHz + x
6696.00 8.00 4.00 ± 10 kHz ± 400 kHz + x
Frequency
(MHz)
Frequency
Span
(MHz)
Selected
Bandwidth
(MHz)
Resolution
(MHz)
Measured
Center
Frequency
(MHz)
Specification Pass/Fail
1000.00 2.00 0.10 ± 5 kHz ± 20 kHz + x
Where X is equal to the Tuned Frequency * (1 ± Frequency Standard in use)
