Keysight NFA Series User Manual

Appendix D 151
Model N8975A: Test Records
Instrument Noise Figure Test Record
Instrument Noise Figure Test Record
Frequency (MHz) Instrument Noise
Figure (dB)
Specification (dB) Pass/Fail
10.00 to 26500 Overall Frequency
Range Result
Test Line Limit
10.00 < 4.425dB
30.00 < 4.475dB
60.00 < 4.550dB
100.00 < 4.650dB
300.00 < 5.150dB
600.00 < 6.710dB
1000.00 < 7.250dB
1500.00 < 7.925dB
2000.00 < 8.600dB
4000.00 < 7.400dB
5000.00 < 10.50dB
6000.00 < 10.50dB
7000.00 < 10.50dB
8000.00 < 10.50dB
9000.00 < 10.50dB
10000.00 < 10.50dB
11000.00 < 10.50dB
12000.00 < 10.50dB
13000.00 < 10.50dB
