Keysight NFA Series User Manual

124 Appendix B
Model N8973A: Test Records
Noise Figure Range and Accuracy Test Record
Results: 20 - 22dB Noise Source ENR
Input
Level
(dBm)
Range
(dB)
Actual
NF (dB)
Measured
NF (dB)
Noise Figure
Measurement
Range (dB)
Instrument
Uncertainty
(dB)
Specification
(dB)
Pass
/Fail
----- 0.125 ± 0.10dB
----- 0.5 ± 0.10dB
-55 1 ± 0.10dB
-56 2 ± 0.10dB
-57 3 ± 0.10dB
-58 4 ± 0.10dB
-59 5 ± 0.10dB
-60 6 ± 0.10dB
-61 7 ± 0.10dB
-62 8 ± 0.10dB
-63 9 ± 0.10dB
-64 10 0 - 35 dB ± 0.10dB
-65 11 ± 0.10dB
-66 12 ± 0.10dB
-67 13 ± 0.10dB
-68 14 ± 0.10dB
-69 15 ± 0.10dB
-70 16 ± 0.10dB
-71 17 ± 0.10dB
-72 18 ± 0.10dB
-73 19 ± 0.10dB
-74 20 ± 0.10dB
-75 21 ± 0.10dB
-76 22 ± 0.10dB
