4 Chapter 1
Preparing for Calibration and Performance Verification Test
Before You Start
Before You Start
Switch on the Noise Figure Analyzer and let it warm up for 1 hour.
Read the rest of this section before you start any of the tests, and make a
copy of the relevant test records for the model you are testing provided in
Appendices A through D.
CAUTION Ensure that the recommended torque settings detailed in Table 1-3 are
adhered to at all times.
CAUTION Ensure that a valid ENR measurement table has been loaded from the C:
or A: drive before carrying out any performance test. The analyzer will
not perform a measurement without an ENR table loaded.
