Technical Specifications
Connectivity
Connectivity
General
GPIB IEEE-488 bus connector
LO GPIB IEEE-488 bus connector dedicated to local oscillator control (SCPI or
custom command set)
Serial RS-232, 9-pin D-SUB male
Printer 25-pin parallel D-Sub female, for connection with IEEE 1284 cable to a
PCL3 or PCL5 compatible printer
VGA Output
1
15-pin mini D-SUB female
Probe Power
(nominal)
+15 Vdc, -12.6 Vdc at 150 mA max.
10 MHz REF OUT 50 Ω nominal BNC (f), >0 dBm
10 MHz REF IN 50 Ω nominal BNC (f), -15 to +10 dBm
Noise Source Drive Output
Connector 50 Ω-type BNC (f)
Output Voltage ON: 28.0 V ±0.1 V at up to 60mA peak
OFF: <1 V
1. 31.5 KHz horizontal, 60 Hz vertical sync rates, non-interlaced, Analog RGB 640 x
480
