Keysight NFA Series - Frequency Accuracy Test Record

108 Appendix A
Model N8972A: Test Records
Frequency Accuracy Test Record
Frequency Accuracy Test Record
Frequency
(MHz)
Frequency
Span
(MHz)
Selected
Bandwidth
(MHz)
Resolution
(MHz)
Measured
Center
Frequency
(MHz)
Specification Pass/Fail
14.00 8.00 4.00 ± 10 kHz ± 100 kHz + x
30.00 8.00 4.00 ± 10 kHz ± 100 kHz + x
60.00 8.00 4.00 ± 10 kHz ± 100 kHz + x
100.00 8.00 4.00 ± 10 kHz ± 100 kHz + x
300.00 8.00 4.00 ± 10 kHz ± 100 kHz + x
600.00 8.00 4.00 ± 10 kHz ± 100 kHz + x
1000.00 8.00 4.00 ± 10 kHz ± 100 kHz + x
1496.00 8.00 4.00 ± 10 kHz ± 100 kHz + x
Where X is equal to the Tuned Frequency * (1 ± Frequency Standard in use)
