102 Chapter 3
Technical Specifications
General Specifications
General Specifications
Data Storage
(nominal)
Internal drive: 30 traces, states or ENR tables
Floppy disk: 30 traces, states or ENR tables
Power
Requirements
On (line 1): 90 to 132 V rms, 47 to 440 Hz
195 to 250 V rms, 47 to 66 Hz
Power consumption <300 W
Standby (line 0): <5 W
Dimensions Without handle: 222mm(H) x 410mm(D) x 375mm(W)
With handle (max): 222mm(H) x 515mm(D) x 409mm(W)
Weight (typical,
without options)
N8972A: 15.3 kg (33.7 lbs.)
N8973A: 15.5 kg (34.2 lbs.)
N8974A: 17.5 kg (38.6 lbs.)
N8975A: 17.5 kg (38.6 lbs.)
Audible Noise <42 dBa pressure and <5.0 bels power (ISODP7779)
Temperature
Range
Operating: 0° C to +55° C
Storage: -40° C to +70° C
Humidity Range Operating Up to 95% relative humidity to 40° C (non-condensing)
Altitude Range Operating to 4,600 meters
Calibration
interval
1-year minimum recommended
