Chapter 2 23

Test Descriptions

Input VSWR

NOTE • denotes test required for associated model number.

NOTE The NFA uses several frequency dependent paths within the front end

assemblies to cover its operating range. It is therefore not possible to

complete a single VSWR swept measurement at a single fixed frequency

point over its entire operating range, as the NFA automatically switches

at approximately 500 MHz and 3000 MHz, dependant on the fixed

frequency setting.

PART 5

TEST VSWR

1500 MHz -3000 MHz

•••

PART 6

CAL VNA 3.0 GHz - 6.7

OR 26.5 GHz

••

PART 7

TEST VSWR

3.0 GHz -6.7 GHz

••

PART 8

TEST VSWR

6.7 GHz -20.0 GHz

•

PART 9

TEST VSWR

20.0 GHz -26.5 GHz

•

Table 2-5 VSWR Frequency Test Bands

N8972A N8973A N8974A N8975A

Keysight NFA Series User Manual
