Appendix D 145
Model N8975A: Test Records
Frequency Accuracy Test Record
15000.00 8.00 4.00 ± 10 kHz ± 400 kHz + x
16000.00 8.00 4.00 ± 10 kHz ± 400 kHz + x
17000.00 8.00 4.00 ± 10 kHz ± 400 kHz + x
18000.00 8.00 4.00 ± 10 kHz ± 400 kHz + x
19000.00 8.00 4.00 ± 10 kHz ± 400 kHz + x
20000.00 8.00 4.00 ± 10 kHz ± 400 kHz + x
21000.00 8.00 4.00 ± 10 kHz ± 400 kHz + x
22000.00 8.00 4.00 ± 10 kHz ± 400 kHz + x
23000.00 8.00 4.00 ± 10 kHz ± 400 kHz + x
24000.00 8.00 4.00 ± 10 kHz ± 400 kHz + x
25000.00 8.00 4.00 ± 10 kHz ± 400 kHz + x
26000.00 8.00 4.00 ± 10 kHz ± 400 kHz + x
26496.00 8.00 4.00 ± 10 kHz ± 400 kHz + x
Frequency
(MHz)
Frequency
Span
(MHz)
Selected
Bandwidth
(MHz)
Resolution
(MHz)
Measured
Center
Frequency
(MHz)
Specification Pass/Fail
1000.00 2.00 0.10 ± 5 kHz ± 20 kHz + x
Where X is equal to the Tuned Frequency * (1 ± Frequency Standard in use)
Frequency
(MHz)
Frequency
Span
(MHz)
Selected
Bandwidth
(MHz)
Resolution
(MHz)
Measured
Center
Frequency
(MHz)
Specification Pass/Fail
