3 Using the Oscilloscope
84 Keysight U1610/20A User’s Guide
– Stopped mode – You can pan and zoom the stored waveform by pressing the
horizontal and vertical control keys. The stopped display may contain several
triggers worth of information, but only the last trigger acquisition is available
for pan and zoom. To ensure the display does not change, change the
triggering mode to the Single acquisition to be sure you have acquired only
one trigger. Pressing and holding also allows you to change to the
Single acquisition.
Continuous mode indicator
Stopped mode indicator
