Front and Rear Panel Features
Front-Panel Features
6 Enter and Arrow Keys The Enter key terminates data entry when either no unit of measure is needed, or you
want to use the current unit.
The arrow keys:
— Increment and decrement the value of the current measurement
selection. (up/down = big increment, left/right = small increment)
— Navigate within tables.
7 Knob Increments and decrements the value of the current active function.
8 Utility Keys The following keys are available in the Utility section:
Numeric key pad
System
Help
Local/Cancel/(Esc)
Back-space
Delete
Control
Alt
Undo/Redo
Touch On/Off
Onscreen Keyboard
Tab
9 RF Input Connector for inputting an external signal. Make sure that the total power of all
signals at the instrument input does not exceed +30 dBm (1 watt).
10 USB Connectors Standard USB 2.0 ports, Type A. Connect to external peripherals such as a mouse,
keyboard, DVD drive, or hard drive.
Proper Ergonomics should be considered when using accessories such as a
keyboard or a mouse.
11 Headphones Output Headphones can be used to hear any available audio output.
12 Probe Power Supplies power for external high frequency probes and accessories.
13 Ext Mixer Provides LO output signal to and receives IF input signals from an external mixer. See
the Specifications Guide for details on signal levels.
14 Power Standby/ On Turns the instrument on. A green light indicates power on. A yellow light indicates
standby mode.
The front-panel switch is a standby switch, not a LINE switch
(disconnecting device). The instrument continues to draw
power even when the front-panel switch is in standby.
The main power cord can be used as the system
disconnecting device. It disconnects the mains circuits from
the mains supply.
15 RF Input 2 Connector for inputting an external signal.
