4 User’s Manual PLZ-5W
RS232C, USB, and LAN communication functions
provided as standard
These functions allow easy incorporation into various
types of inspection systems.
GPIB function available as option*
Using the optional GPIB converter （p.171）, the GPIB
function can be used via the RS232C or USB interface.
* Limitation apply to some of the functions.
• In this manual, electronic load PLZ205W, PLZ405W, or
PLZ1205W is sometimes referred to as PLZ-5W.
• The term “PC” is used to refer generally to both personal
computers and workstations.
• The term “DUT” is used to refer generally to a device
under test.
• The screen captures and illustrations used in this text
may differ from the actual items.
• The following markings are used in the explanations of
this text.
Indicates a potentially hazardous situation which, if
ignored, could result in death or serious injury.
Indicates a potentially hazardous situation which, if
ignored, may result in damage to the product or other
property.
Indicates information that you should know.
Indicates a reference manual (CD-ROM) containing
detailed information.
>
Indicates the hierarchy of items you need to select. The
item to the left of this symbol indicates a higher level
item.
When using this product, be sure to observe the “Safety
Precautions” in the Safety Information manual. The follow-
ing precautions pertain only to this product.
• The rear panel may become hot during operation. If you
touch it, you may burn yourself.
When installing this product, be sure to observe the “Pre-
cautions When Choosing the Installation Location” in the
Safety information manual. The following precautions per-
tain only to this product.
• When installing this product, be sure to observe the tem-
perature and humidity ranges indicated below.
Operating temperature range: 0 °C to 40 °C
(32 °F to 104 °F)
Operating humidity range: 20 %rh to 85 %rh
(no condensation)
• When storing this product, be sure to observe the tem-
perature and humidity ranges indicated below.
Storage temperature range: -20 °C to 70 °C
(-4 °F to 158 °F)
Storage humidity range: 90 %rh or less (no condensation)
• Do not install the product vertically.
It may cause injury to the operator or damage to the
product when it falls down.
Notations Used in This Manual
Precautions Concerning
Installation Location
