PLZ-5W User’s Manual 5
Contents
About the PLZ-5W Series Manuals ....................2
Accessories ........................................................3
Product Overview ...............................................3
Notations Used in This Manual...........................4
Safety Precautions .............................................4
Precautions Concerning Installation Location ....4
Component Names ............................................8
Installation and Preparation
Connecting the Power Cord .............................12
Checking Whether the Power Is On or Off .......13
Turning the power on............................................ 13
Turning the power off............................................ 13
Connecting to the DUT.....................................14
Connecting to the load input terminals on the rear
panel..................................................................... 15
Connecting to the load input terminals on the front
panel..................................................................... 17
Notes regarding load input terminals .................... 18
Basic Functions
Panel Operations..............................................19
Switching the display ............................................ 19
Using the function keys ........................................ 20
Inputting numbers and characters ........................ 22
Changing values................................................... 23
Load On/Off......................................................24
Setting the Operation Mode .............................25
Setting the operation mode .................................. 25
Setting the current in CC mode ............................ 26
Setting the conductance in CR mode ................... 26
Setting the voltage in CV mode ............................ 27
Setting the power in CP mode.............................. 27
Setting the load value in CC+CV mode ................ 28
Setting the load value in CR+CV mode ................ 29
Setting the load value in ARB mode..................... 30
Setting the Current Range and Voltage Range34
Setting the Slew Rate.......................................35
Setting the Short Function................................36
Switching Function ...........................................37
Setting the switching level .................................... 37
Setting the switching interval ................................ 38
Turning the switching function on/off.................... 39
Timing of trigger signal output .............................. 39
Alarm Function .................................................40
Alarm types and operation ................................... 40
Setting overcurrent protection (OCP) ................... 42
Setting overpower protection (OPP)..................... 43
Setting undervoltage protection (UVP)................. 44
Setting watchdog protection (WDP) ..................... 45
When an alarm occurs ......................................... 45
Clearing an alarm................................................. 46
Recording Measurements ................................47
Starting measurement recording .......................... 47
Obtaining measurements ..................................... 47
Setting recording conditions ................................. 48
Aborting a measurement recording ...................... 50
Recording Integrated Data ...............................51
Recording current capacity, power capacity, and
elapsed time ......................................................... 51
Showing or hiding integrated data........................ 53
Advanced Functions
Changing the Response Speed .......................54
Soft Start ..........................................................55
Remote Sensing...............................................56
Connecting the sensing cables ............................ 56
Enabling or disabling remote sensing .................. 57
Auto Load Off Timer.........................................58
Types of Memory .............................................59
ABC Preset Memories......................................60
Saving to ABC preset memories .......................... 61
Recalling ABC preset memory entries ................. 62
Setup Memory..................................................63
How to view the setup memory edit screen.......... 63
Saving to the setup memory................................. 64
Checking the setup memory details ..................... 66
Recalling the setup memory................................. 66
Synchronized Operation...................................67
Connection for synchronized operation................ 67
Synchronizing the load on/off operation ............... 69
Synchronizing measurement recording................ 70
Synchronizing the start of sequences .................. 71
Synchronizing the resuming of sequences........... 72
Aborting synchronized operation.......................... 72
Remote Control ................................................73
Releasing remote control ..................................... 73
