6.d - Selection of the channel for visual and relays alarms
6. Alarm / relay settings
F400
Page 12
Class 200 transmitters have 4 alarms: 2 visual (LED) and audible alarms and 2 relay alarms. The transmitter can be
configured with 4 different alarms setups.
1
> F 100
Step
Go into configuration mode (see page 2). The folder number displayed
corresponds to the last configuration folder used.
2
> F 400
Step
Select the folder “400” and validate with .
01
3
F 402
Step
>
4
Step
With and keys, select the channel number for which you want to
configure an alarm. Validate with .
01
F 402
>
01
5
F 402
Step
The cursor > returns to sub-folders line.
• press twice to return to reading mode.
• press once to return to another folder selection.
• with and keys, you can choose another sub-folder from the folder 400
(i.e. for example to configure another alarm / relay)
>
“402” “407” “412” “417”
Alarm 1 Alarm 2 Relay 1 Relay 2
Select sub-folder
and validate with .
!
Before any alarm setup, check that the corresponding channel(s) is activated.
(Led 1) (Led 2)
Class 200 transmitter configuration via keypad
